CAT 324

star

5

Ex-Showroom Price

₹ 46 L - 52.99 L

Diesel

Diesel

22700 kg

22700 kg

6310 mm

6310 mm

Download CAT 324 Brochure

Download CAT 324 brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of CAT 324

Engine Power

Engine Power

150 HP

Operating Weight

Operating Weight

22700 kg

Bucket capacity

Bucket capacity

1 Cu.m

Hydraulic system

Hydraulic system

416 L/min

Maximum Digging Depth

Maximum Digging Depth

6310 mm

Boom Height

Boom Height

5.7 m

About CAT 324 Overview

The Cat 324 is a high performance hydraulic excavator designed to balance brute strength with refined control for high production workloads. With an operating weight of 22,700 kg, it provides the stab...

CAT 324 Specifications & Features

Engine

Engine ModelCat® C7.1
Gross Power162 kW
Net Power145 kW
Engine Power150 HP
Displacement7100 cc
Number of Cylinders6 Nos
Rated RPM2000 rpm
Emission StandardBS IV
Max Torque1050 Nm
Fuel TypeDiesel

Operating Weights

Operating Weight22700 kg
Machine Weight21500 kg
Counterweight4800 kg
Ground Pressure47 kPa

Hydraulic System

Main Pump TypeVariable Displacement Axial Piston
Maximum Hydraulic Flow416 L/min
Maximum System Pressure350 bar
Hydraulic Oil Capacity240 litres
Auxiliary Hydraulic Flow180 L/min

Working Range

Maximum Digging Depth6310 mm
Maximum Vertical Wall Digging Depth5620 mm
Maximum Reach at Ground Level9470 mm
Maximum Dumping Height7000 mm
Maximum Cutting Height9330 mm
Boom Length5.700 m
Arm Length2900 mm
Bucket Breakout Force150 kN
Arm Tear-out Force110 kN

CAT 324 EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹1,00,100

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount₹45,00,000
Interest Amount (12 %)₹15,06,001
Total Amount Payable₹60,06,001

CAT 324 Pros and cons

like

Pros

  • 150 HP Cat C7.1 engine delivers strong power for high production.
  • Advanced electrohydraulic system ensures smooth and faster cycle times.
  • Eco Mode and automatic engine speed control help reduce fuel consumption.
    • dislike

    Cons

  • Higher operating weight may limit use in very tight job sites.
  • Advanced electronic and hydraulic systems can increase maintenance.

    • Download CAT 324 Brochure PDF

    Download CAT 324 brochure online. Check out the CAT 324 PDF brochure at Only Heavy with all features and specifications.

    CAT 324 Uses

    uses

    Excavation

    uses

    Digging

    uses

    Loading

    uses

    Construction

    uses

    Material handling

    uses

    Trenching

    CAT 324 Loan Offers
