Mahindra EarthMaster VX IV

star

5

Ex-Showroom Price

₹ 25 L - 26 L

Diesel

Diesel

0.27 Cu.m

0.27 Cu.m

4959 mm

4959 mm

Download Mahindra EarthMaster VX IV Brochure

Download Mahindra EarthMaster VX IV brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of Mahindra EarthMaster VX IV

Max. reach at full height

Max. reach at full height

1115 m

Max Operating Weight

Max Operating Weight

7584 kg

Loader Bucket capacity

Loader Bucket capacity

1.1 Cu.m

Backhoe Bucket capacity

Backhoe Bucket capacity

0.27 Cu.m

Max Dig Depth

Max Dig Depth

4959 mm

Max. lift capacity

Max. lift capacity

3428 kg

About Mahindra EarthMaster VX IV Overview

The Mahindra EarthMaster VX IV is a mid-range backhoe loader designed for general construction, earthmoving, trenching, and material handling. It’s positioned as a cost-effective alternative to higher...

Mahindra EarthMaster VX IV Specs & Features

Engine

ModelVNEF 3.5 L Turbocharged Intercooled
Engine Displacement3532 cc
Engine Power74 hp
Maximum torque345 Nm
Fuel TypeDiesel
Transmission TypeFour Speed (4 Forward, 4 Reverse)

Loader General

Dump height2708 mm
Load over height1350 mm
Hinge pin height3550 mm
Max reach at full height (bucket dumped)1115
Loader Bucket capacity1.1 Cu.m
Bucket breakout force6250 Kgf
Max Pay Load2000 Kg
Dump Angle40 Degree
Loader Arm Breakout Force5600 kgf

Backhoe

Max dig depth4959 mm
Max working height6043 mm
Backhoe bucket capacity0.27 Cu.m
Bucket rotation180 Degree
Dipper tear out force3300 Kgf
Max lift capacity3428 Kg
Max Load Over Height4131 mm

Overall Dimension & Weight

Max operating weight7584 Kg
Transport length5700 mm
Width over stabilizer / bucket2800 mm
Wheelbase-
Minimum ground clearance350 mm
Height to top of cabin3300 mm

Mahindra EarthMaster VX IV EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹53,387

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount₹24,00,000
Interest Amount (12 %)₹8,03,200
Total Amount Payable₹32,03,200

Mahindra EarthMaster VX IV Pros and cons

like

Pros

  • Generally priced lower than many competing backhoe loaders, making it appealing for small to mid-scale operations.
  • Adequate 74 HP engine delivering useful torque for most general jobs.
  • Ergonomically designed cabin improves comfort and reduces operator fatigue.
    • like

    Cons

  • Engine power and torque are not the highest in the class when compared with some competitors (e.g., higher-power loaders).
  • Most comparisons list a 120 L fuel tank, which is smaller than some rivals, meaning slightly reduced operational range.
  • Digging depth and lift capacity are less than premium machines like JCB 4DX, which may matter on heavy excavation sites.

    • Download Mahindra EarthMaster VX IV Brochure

    Download Mahindra EarthMaster VX IV brochure online. Check out the Mahindra EarthMaster VX IV PDF brochure at Only Heavy with all features and specifications.

    Mahindra EarthMaster VX IV Uses

    uses

    Material Handling

    uses

    Goods Delivery

    uses

    Excavation

    uses

    Digging

    uses

    Loading

    Mahindra EarthMaster VX IV Loan Offers

    location

    Explore Mahindra EarthMaster VX IV Alternatives

    ACE AX-124New

    ACE AX-124

    Engine Power

    3783 CC

    Bucket Capacity

    1.1 Cu.m

    Digging Depth

    4250 mm

    Ex-showroom Price

    ₹ 23 L - 31 L

    BOBCAT B900 Xtra CEV-VNew

    BOBCAT B900 Xtra CEV-V

    Engine Power

    2500 CC

    Bucket Capacity

    1 Cu.m

    Digging Depth

    4200 mm

    Ex-showroom Price

    ₹ 18 L - 20 L

    Bull GRANDIA Backhoe LoaderNew

    Bull GRANDIA Backhoe Loader

    Engine Power

    4400 CC

    Bucket Capacity

    1.1 Cu.m

    Digging Depth

    4600 mm

    Ex-showroom Price

    ₹ 37 L - 37.99 L

    CASE 770 NX New

    CASE 770 NX

    Engine Power

    3900 CC

    Bucket Capacity

    1.1 Cu.m

    Digging Depth

    4400 mm

    Ex-showroom Price

    ₹ 35 L - 37.01 L

    CAT 424New

    CAT 424

    Engine Power

    3600 CC

    Bucket Capacity

    1 Cu.m

    Digging Depth

    4707 mm

    Ex-showroom Price

    ₹ 34 L - 34.99 L

    ESCORTS BLX75K New

    ESCORTS BLX75K

    Engine Power

    3680 CC

    Bucket Capacity

    1.1 Cu.m

    Digging Depth

    4770 mm

    Ex-showroom Price

    ₹ 38 L - 39.99 L

    JCB 3DXNew

    JCB 3DX

    Engine Power

    4800 CC

    Bucket Capacity

    1.1 Cu.m

    Digging Depth

    4770 mm

    Ex-showroom Price

    ₹ 35 L - 38 L

    JB Industries JBI-06New

    JB Industries JBI-06

    Engine Power

    2900 CC

    Bucket Capacity

    1 Cu.m

    Digging Depth

    4600 mm

    Ex-showroom Price

    ₹ 22 L - 23.99 L

    Calculate your Monthly Fuel Cost

    The calculations provide an estimated amount, but actual figures may vary depending on local fuel prices, electricity rates, and other factors

    Daily Fuel Usage (Litres)

    48 Litres Per Day

    Daily Fuel Cost

    ₹4560 Per Day

    Monthly Fuel Cost

    ₹118560 Per Month

    Petrol pump

    Compare Top BackHoe Loaders

    Mahindra EarthMaster VX IV ACE AX-124

    VS

    Mahindra EarthMaster VX IV

    ACE AX-124

    ₹ 25 L - 26 Lvs₹ 23 L - 31 L
    Compare Now
    Mahindra EarthMaster VX IV BOBCAT B900 Xtra CEV-V

    VS

    Mahindra EarthMaster VX IV

    BOBCAT B900 Xtra CEV-V

    ₹ 25 L - 26 Lvs₹ 18 L - 20 L
    Compare Now
    Mahindra EarthMaster VX IV Bull GRANDIA Backhoe Loader

    VS

    Mahindra EarthMaster VX IV

    Bull GRANDIA Backhoe Loader

    ₹ 25 L - 26 Lvs₹ 37 L - 37.99 L
    Compare Now
    Mahindra EarthMaster VX IV CASE 770 NX

    VS

    Mahindra EarthMaster VX IV

    CASE 770 NX

    ₹ 25 L - 26 Lvs₹ 35 L - 37.01 L
    Compare Now
    Mahindra EarthMaster VX IV CAT 424

    VS

    Mahindra EarthMaster VX IV

    CAT 424

    ₹ 25 L - 26 Lvs₹ 34 L - 34.99 L
    Compare Now
    Mahindra EarthMaster VX IV ESCORTS BLX75K

    VS

    Mahindra EarthMaster VX IV

    ESCORTS BLX75K

    ₹ 25 L - 26 Lvs₹ 38 L - 39.99 L
    Compare Now
    Mahindra EarthMaster VX IV JCB 3DX

    VS

    Mahindra EarthMaster VX IV

    JCB 3DX

    ₹ 25 L - 26 Lvs₹ 35 L - 38 L
    Compare Now
    Mahindra EarthMaster VX IV JB Industries JBI-06

    VS

    Mahindra EarthMaster VX IV

    JB Industries JBI-06

    ₹ 25 L - 26 Lvs₹ 22 L - 23.99 L
    Compare Now

    Talk to Dealer

    Find nearest dealer in your area with us and fulfil your dreams by buying the best backhoe loader matching your needs.

    FAQs on Mahindra EarthMaster VX IV

    Do you have more questions?

    End-to-end payments and financial management in a single solution. Meet the right platform to help realize.

    What is the EarthMaster VX IV best suited for?

    How powerful is the engine?

    Does it have an AC cabin?

    What is the hydraulic pressure?

    How does it compare to other backhoes like JCB 4DX?
